| Thermal Imaging |
| Detector Type |
Uncooled infrared detector
|
| Infrared Resolution |
1280×1024
|
| Pixel Size |
12μm
|
| Super Resolution |
2560×2048
|
| Spectral Band |
7.5-14μm
|
| NETD |
＜25mK (25°C,F1.0)
|
| Frame Rate |
30 Hz
|
| Lens Focal Length |
Standard lens: 34.9mm; wide-angle lens: 19.8mm; telephoto lens: 72.9mm; macro lens (0.2×): 17.8mm; super macro lens (0.4×): 15.2mm
|
| FOV |
Standard lens: 25°×20°; telephoto lens: 12°×9.6°; wide-angle lens: 45°×36°
|
| IFOV |
Standard lens: 0.34mrad; telephoto lens: 0.17mrad; wide-angle lens: 0.6mrad; macro lens: One pixel corresponds to 50μm; super macro lens: One pixel corresponds to 25μm.
|
| Focusing Mode |
Manual focus,electri micro focus, one-button center focus, automatic center focus,single-touch automatic focus, laser-assisted focus
|
| Minimum Imaging Distance |
Standard lens: 0.5m; telephoto lens: 2.3m; wide-angle lens: 0.2m; macro lens: 46mm; super macro lens: 13mm;
|
| Measurement Range |
Standard: -20°C~+150°C (low temperature range), 150°C~800°C (medium temperature range), 400°C~2000°C, other ranges (high temperature range)
|
|
| Imaging Display |
| Display |
5.5-inch LCD touch screen, resolution 1920×1080
|
| Visible Light Camera |
13 megapixels
|
| Digital Zoom |
1–15 times, continuously adjustable roller
|
| Palettes |
19 options
|
| Image Mode |
Infrared, visible light, PIP, dual-spectrum fusion
|
| Temperature Width Stretch |
Support
|
|
| Measurement and Analysis |
| Laser Rangefinding |
Support
|
| Area Measurement |
Support
|
| Position |
Support
|
| Temperature Difference Analysis |
Support
|
| Trend Analysis |
Supports temperature trend recording and analysis.
|
| Image Freezing |
Support
|
| Analysis Report |
PDF format. Support editing and template importing on the PC client.
|
| Supporting Software |
PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
|
|
| Image Storage |
| Storage Medium |
Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB.
|
| Text Notes |
Support
|
| Voice Annotation |
Support
|
|
| Video Functions |
| Radiation Infrared Video Recording |
Support compressed full radiation video recording (.irv), up to 15Hz video recording
|
| Non-radiation Infrared or Visible Light Video Recording |
Standard MP4 video recording
|
| Radiation Infrared Video Stream Transmission |
Analysis at about 25Hz on PC
|
| Non-radiation Infrared Video Stream Transmission |
RTSP H.264
|
| Video Resolution |
1920×1080
|
|
| System Functions |
| Intelligent Image Stabilization |
Support
|
| Intelligent Panoramic Stitching |
Support
|
| Intelligent Routine Inspection |
Support. General task package import and editing, standard and automatic naming of images
|
| Routine Inspection Record Self-inspection |
Support
|
| Dual-Spectrum Video Recording |
Simultaneous infrared video and visible light video recording, in MP4 format.
|
| Communication Protocol |
Wi-Fi, Bluetooth, USB
|
| Voice Control |
Voice assistant, quick command recognition
|
| Flashlight |
Support
|
|
| Others |
| Microphone/Speaker |
Support
|
| Battery |
9000mAh lithium-ion battery, field-replaceable, fast charging
|
| Charging Mode |
USB Type-C or desktop charger
|
| Battery Life |
Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions)
|
| Interface |
USB3.0 Type-C, SD card, SIM card, Mini HDMI
|
| Tripod Socket |
UNC 1/4-20 interface for tripod
|
| Operating Temperature |
‘-15°C~+50°C
|
| Operating Humidity |
10%~95% (non-condensing)
|
| Storage Temperature |
-40°C~+70°C
|
| Ingress Protection Rating |
IP54
|
| Shock and Vibration |
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
| Weight and Dimensions |
<1.7kg (with battery), 140×210×115mm
|
| Authentication |
CE/RoHS/CMA, etc.
|
|
